30L Deep-Basin Heavy-Duty 25kHz Ultrasonic Washer — 800W Power-Adjustable Bath with Sweep & Pulse Modes
$1,245.00 piece
| Quantity | Price | Discount |
|---|---|---|
| 2-20 | $1,182.75 piece | 5% |
| 21-100 | $1,120.50 piece | 10% |
| 101+ | $1,058.25 piece | 15% |
Shipping & Delivery
-
Express Air Delivery
Door-to-door with tracking
7-15 Business Days
Calculated at checkout
-
Standard Ocean Freight
Best for bulk & heavy cargo
25-35 Business Days
Calculated at checkout
-
Warranty 1 year
-
Free 30-Day returns
Specification
Overview
| Model | GNL1630-25 |
|---|---|
| Brand | Granbo |
| Manufacturer | Granbo Technology Industrial Shenzhen Co., Ltd. |
| Origin | China |
| Capacity | 30L |
| Frequency | 25kHz |
| Power | 0–800W |
| Tank Material | SUS304 Stainless Steel |
| Housing Material | SUS304 Stainless Steel |
| Function | Degassing, Digital Control, Heating, Noise Reduction, Power Adjustable, Pulse, Semiwave, Sweep, Timer |
| Heater | RT~80°C |
| Timer | 1-9999s |
| Tank Size(mm) | 500 x 300 x 200 |
| Unit Size(mm) | 600 x 360 x 430 |
| Voltage | 100V-120V ~ 60Hz / 220V-240V ~ 50Hz |
| Plug Type | AU Plug, EU Plug, Other Plugs, UK Plug, US Plug |
| Warranty | 1 Year |
| Customization | 485 Port, Frequency, PLC System, Tanks Numbers |
| Certificates | CE, FCC, ISO 9001, RoHS |
| Applications | Coarse Dispersion, Cutting Dust Removal, Emulsification, Engine Blocks, Heavy Rust Removal, Motor Housings, Polishing Wax, Resin Molds, Scale Buildup, Solvent Degassing |
Packaging
| Chargeable Weight | 60 kg |
|---|---|
| Package Dimensions | 75 × 45 × 53 cm |
Description
Intensive 25kHz Low-Frequency Impact & Acoustic Shear Force
Operating at a low 25kHz frequency, this system generates large cavitation bubbles that collapse with powerful physical impact. This strong acoustic scrubbing force effectively dislodges thick oil films, heavy rust layers, stubborn scale, cutting dust, resin burrs, and hardened polishing wax from durable metal surfaces and hard resin components. In addition to heavy surface decontamination, the 25kHz transducer array produces substantial acoustic shear force, making it highly efficient for sonochemical fluid processing, including coarse solid dispersion, liquid emulsification, and rapid solvent deaeration.
Generous 30L Deep Tank & Heavy-Duty Construction
Built with an expansive 30L capacity and interior dimensions of 50 x 30 x 20 cm, the deep-basin architecture is engineered for bulk batch cleaning and taller physical workpieces. It easily accommodates bulky engine blocks, heavy industrial castings, large resin molds, tall beaker arrays, and high-volume hardware components. To endure continuous low-frequency acoustic shock, the internal chamber is crafted from 2.0mm thick SUS304 stainless steel and joined using heavy manual oxy-acetylene welding to prevent cavitation erosion and structural fatigue.
Suitable Workpieces & Target Applications
- Heavy Mechanical Parts & Castings: Cleans bulky engine blocks, motor housings, heavy resin molds, iron castings, and high-volume fasteners.
- Tough Industrial Contaminants: Strips thick grease, heavy rust, baked-on carbon deposits, scale buildup, cutting dust, and polishing wax.
- Sonochemical Fluid Processing: Supports coarse solid dispersion, heavy liquid emulsification, particle homogenization, and solvent degassing.
800W Variable Power Drive & Multi-Mode Digital Controls
- 0–800W Adjustable Power: Driven by 16 high-performance 50W transducers, allowing full digital control from delicate fluid agitation up to 800W full-force cleaning.
- Sweep & Pulse Operating Modes: Sweep mode varies the sound frequency around 25kHz to prevent standing wave dead zones across the 50cm bath, while Pulse mode delivers periodic power peaks to break up tough surface crusts.
- Rapid Degas & Thermal Assist: Degas mode swiftly removes entrapped air bubbles from solutions to maximize cavitation intensity, complemented by an RT–80°C heating system to melt grease and wax.
Control Panel Overview
Control Button Guide
Sweep Frequency Technology Overview
Pulse Mode Overview
Granbo PCB vs. Standard Ultrasonic Cleaner PCB
Multi-Layer Noise Reduction Design
Box Contents:
- 1 x Professional Ultrasonic Cleaner
- 1 x Durable Mesh Cleaning Basket
- One cover, one power cord, one manual warranty card certificate of conformity.
Packing type:
- One unit filled with thick foam, then standard export corrugated carton or wooden box.
Real Customer Feedback
Support & FAQ
Frequency determines cavitation bubble size, impact force, and penetration depth. Lower frequencies produce violent impact for heavy dirt, while higher frequencies provide dense, gentle cleaning for sub-micron microstructures:
• 28kHz: Heavy oil, scale, rust, polishing wax, cutting dust, and thick contaminants (>10μm) on heavy metal/resin parts.
• 40kHz: Universal choice for standard labware, stainless steel, glass, and general maintenance (>10μm particles).
• 68kHz / 80kHz: Fine cleaning for PCBs, watch components, optics, medical instruments, and micro-grooves (5–10μm particles).
• 120kHz: Precision cleaning for micro-blind holes (<0.1mm), semiconductors, ICs, optical lenses, and MEMS (1–5μm particles).
• 200kHz: Ultra-precision cleaning for silicon wafers, MEMS, thin films, and sub-micron / nano-scale contamination (<1μm).
Based on Granbo multi-frequency switchable configurations (Single/Dual/Triple/Quad), we recommend:
| Process | Recommended Frequency | Application Context |
|---|---|---|
| Dispersion | 17-28kHz / 40kHz / 120kHz | 17-28kHz for coarse solid chunks; 40kHz for powders; 120kHz for micro/nano suspensions. |
| Emulsification | 28kHz / 40kHz | 28kHz generates stronger shear force for heavy liquid blending. |
| Extraction | 40kHz / 120kHz | 120kHz is standard for intracellular substance extraction and cell disruption. |
| Mixing/Catalysis | 40kHz / 120kHz | 40kHz for routine mixing; 120kHz for micro-particle homogenization. |
| Synthesis | 80kHz / 120kHz | Prevents molecular degradation during material synthesis. |
| Environmental | 20kHz | High-power sonication for sludge treatment, sewage, and algae disruption. |
To resist cavitation erosion, Granbo customizes tank thickness and welding based on operating frequency:
| Frequency Range | Inner Tank (SUS304) | Outer Shell | Common Tank Capacities & Process |
|---|---|---|---|
| 28kHz - 200kHz | 1.5 mm Thickness | SUS304 (1.0 mm) | 3–10L, 14–22L, 30–58L, 61–135L. Industrial precision stamping & TIG welding. |
| 25kHz | 2.0 mm Thickness | SUS201 (1.0 mm) | Thickened tank; Manual oxy-acetylene heavy welding. |
| 17kHz & 20kHz | 3.0 mm Thickness | SUS201 (1.0 mm) | Ultra-thickened tank; Manual oxy-acetylene heavy welding. |
*Material Safety Tip: Soft metals (aluminum, brass, gold) and delicate glass/ceramics may scratch or fracture at 28kHz. We recommend 40kHz to 80kHz or pre-testing for delicate substrates.
When a workpiece has both stubborn contaminants and sub-micron precision requirements, use a multi-stage approach:
- Stage 1 (Pre-cleaning / 28kHz or 40kHz): Strips heavy grease, rust, polishing paste, scale, or coarse metal particles.
- Stage 2 (Fine Cleaning / 68kHz or 80kHz): Removes fine particles (5–10μm) from blind holes, threads, and complex internal geometry.
- Stage 3 (Ultra-Precision Rinse / 120kHz or 200kHz): Eliminates sub-micron (<1μm) residues without damaging fragile surfaces or thin films.
- Sweep Mode: Automatically sweeps ±1kHz around the center frequency to eliminate standing waves, ensuring uniform cavitation across the bath.
- Degas Mode: Uses pulsed ultrasound intervals (e.g., 5s on / 5s off) to purge dissolved air/gas from liquids—crucial for HPLC sample prep and max cavitation efficiency.
- Pulse Mode: Rapidly cycles power from 100% to 0% to produce a "blasting" impact that removes tough or baked-on residues.
Granbo units utilize Full-Bridge Separately Excited PCB Driver Boards rather than cheap self-excited circuits:
- Visualized Real-time Data: Displays live Power, Frequency, and Current for strict laboratory protocol logging.
- High Power Density: Guarantees a standard ≥ 0.3W/cm² for thorough cleaning. Power Density = Ultrasonic Power (W) / Radiating Area (cm²)
- Low Noise Operation: While 28kHz operation naturally produces more audible mechanical noise, Granbo's multi-layer noise-reduction design enables high-frequency units (≥68kHz) to operate at noise levels below 80dB.
Ultrasonic frequency determines sound wavelength and cavitation bubble collapse intensity:
- 20kHz (λ ≈ 72.5mm): Large bubbles, high collapse force. Best for heavy rust, sludge, and thick scale.
- 40kHz (λ ≈ 36.2mm): Medium bubbles. Ideal balance between cleaning power and component safety.
- 120kHz (λ ≈ 12.0mm): Micro bubbles. High penetration depth for sub-micron cracks and fragile silicon/semiconductor parts.
Beaker Size Matching:
• Beaker ≤ 500mL → 3.2L to 6.5L Tank.
• Beaker ≥ 800mL → 10L to 30L Tank (10L is the most popular size for general lab applications).
Temperature Management:
Ultrasonic activity inherently raises liquid temperature. Although Granbo heating goes up to 80°C, cavitation effectiveness drops significantly above 72°C–80°C due to increased vapor pressure. For temperature-sensitive or low-temp processes, use cooling coils or ice packs in the bath.
Standard production lead times for out-of-stock or customized Granbo models:
- 28kHz - 200kHz Models (Single, Dual, Triple, Quad Frequency): 3 - 5 business days for shipping.
- Ultra-Low Frequency (17kHz, 20kHz, 25kHz): 14 - 20 business days for shipping.
*Note: Customizations like RS-485 communication or PLC integration may slightly adjust delivery timelines. Contact us for precise scheduling.
More Models & Specifications
Click a model name to view its corresponding product page and detailed specifications.
25kHz Series
| Model | Transducers
(PCS) |
Capacity
(L) |
Tank Size
(LxWxH mm) |
Unit Size
(LxWxH mm) |
Frequency
(kHz) |
Ultrasonic Power
(W) |
Heating Power
(W) |
Temp.
(C) |
Timer
(S) |
| GNL0303-25 | 3 | 3.2 | 240x135x100 | 340x195x320 | 25 | 0-150 | 300 | 20-80 | 1-9999 |
| GNL0305-25 | 3 | 4.8 | 240x135x150 | 340x195x370 | 25 | 0-150 | 300 | 20-80 | 1-9999 |
| GNL0404-25 | 4 | 4.5 | 300x150x100 | 400x210x220 | 25 | 0-200 | 450 | 20-80 | 1-9999 |
| GNL0406-25 | 4 | 6.5 | 300x150x150 | 400x210x370 | 25 | 0-200 | 450 | 20-80 | 1-9999 |
| GNL0810-25 | 8 | 10 | 300x240x150 | 400x300x370 | 25 | 0-400 | 600 | 20-80 | 1-9999 |
| GNL0814-25 | 8 | 14 | 300x240x200 | 400x300x420 | 25 | 0-400 | 600 | 20-80 | 1-9999 |
| GNL1015-25 | 10 | 15 | 330x300x150 | 430x360x370 | 25 | 0-500 | 1000 | 20-80 | 1-9999 |
| GNL1019-25 | 10 | 19 | 330x300x200 | 430x360x420 | 25 | 0-500 | 1000 | 20-80 | 1-9999 |
| GNL1622-25 | 16 | 22 | 500x300x150 | 600x360x380 | 25 | 0-800 | 1000 | 20-80 | 1-9999 |
| GNL1630-25 | 16 | 30 | 500x300x200 | 600x360x430 | 25 | 0-800 | 1000 | 20-80 | 1-9999 |
30L Capacity
| Model | Transducers (PCS) |
Capacity (L) |
Tank Size (L×W×H mm) |
Unit Size (L×W×H mm) |
Frequency (kHz) |
Ultrasonic Power (W) |
Heating Power (W) |
Temp. (°C) |
Timer (S) |
|---|---|---|---|---|---|---|---|---|---|
| GNLH1430-17 | 14 | 30 | 500×300×200 | 600×360×430 | 17 | 0–1120 | 1000 | 20–80 | 1–9999 |
| GNLH1430-20 | 14 | 30 | 500×300×200 | 600×360×430 | 20 | 0–1400 | 1000 | 20–80 | 1–9999 |
| GNL1630-25 | 16 | 30 | 500×300×200 | 600×360×430 | 25 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1430-28 | 14 | 30 | 500×300×200 | 530×330×395 | 28 | 0–700 | 1000 | 20–80 | 1–9999 |
| GL1430-33 | 14 | 30 | 500×300×200 | 530×330×395 | 33 | 0–700 | 1000 | 20–80 | 1–9999 |
| GL1030-40 | 10 | 30 | 500×300×200 | 530×330×385 | 40 | 0–500 | 1000 | 20–80 | 1–9999 |
| GLS3230-50 | 32 | 30 | 500×300×200 | 530×330×385 | 50 | 0–960 | 1000 | 20–80 | 1–9999 |
| GLS3230-53 | 32 | 30 | 500×300×200 | 530×330×385 | 53 | 0–1120 | 1000 | 20–80 | 1–9999 |
| GL1630-68 | 16 | 30 | 500×300×200 | 530×330×395 | 68 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1630-80 | 16 | 30 | 500×300×200 | 530×330×385 | 80 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1630-120 | 16 | 30 | 500×300×200 | 530×330×385 | 120 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1630-130 | 16 | 30 | 500×300×200 | 530×330×385 | 130 | 0–960 | 1000 | 20–80 | 1–9999 |
| GLS3230-200 | 32 | 30 | 500×300×200 | 530×330×385 | 200 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1430-2840 | 14 | 30 | 500×300×200 | 530×330×395 | 28/40 | 0–700 | 1000 | 20–80 | 1–9999 |
| GL1630-4068 | 16 | 30 | 500×300×200 | 530×330×395 | 40/68 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1630-4080 | 16 | 30 | 500×300×200 | 530×330×385 | 40/80 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1630-40120 | 16 | 30 | 500×300×200 | 530×330×385 | 40/120 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1630-80120 | 16 | 30 | 500×300×200 | 530×330×385 | 80/120 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1630-255080120 | 16 | 30 | 500×300×200 | 530×330×385 | 25/50/80/120 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1630-4080100160 | 16 | 30 | 500×300×200 | 530×330×385 | 40/80/100/160 | 0–800 | 1000 | 20–80 | 1–9999 |
| GL1630-4080120170 | 16 | 30 | 500×300×200 | 530×330×385 | 40/80/120/170 | 0–800 | 1000 | 20–80 | 1–9999 |
